Slimlite
This slim box at only 80mm thick has been engineered to offer excellent value for money. Slimlite offers superior lighting characteristics by utilising patented techniques and is available in both the standard and the enhanced Fulfil™ lighting configurations.
Benefits
- Thin low profile design at only 80mm deep
- Excellent value for money
- Field replaceable PETG glazing
- Standard and Fulfil™ lighting options
- Electronic lighting ballasts
- Indoor Use
- Aluminum construction with powdered-coated paint finishing to customer colour specification
- Wall mounted static poster
| Outline Specification |
| |
|
|
| Poster Size |
: |
1800 X 1200 mm |
| Safe Area |
: |
1760 x 1160 mm |
| Overall Size |
: |
4 tube 1910 x 1310 x 80mm |
| |
|
Fulfil™ 6 Tube 1930 x 1330 x 80mm |
| Glazing |
: |
3mm Clear PETG |
| Diffuser |
: |
Net poster support |
| Posting |
: |
Dual poster clip poster retaining system. Other options available. |
| Locking |
: |
Sliding Locks |
| Lighting |
: |
Electronic ballasts and T5 tubes |
| Door |
: |
Top Hinged or Side Hinged |
| Voltage |
: |
230 VAC, 50 Hz |
| Power |
: |
4 Tube 118W or 6 Tube 186W (typical consumption) |
| SIGN TYPE |
DIMENSIONS [mm] |
MASS |
| |
|
|
| Wall mounted [static] |
2085 x 1484 x 127 |
130kg |
|
|
