Steelhaus
Stainless steel, aluminium and glass are used to great effect to create this very stylish and top-end range of mall and airport products. These are available in free-standing and wall-mounted configurations for static and scrolling poster displays.
Benefits
- Handsome stainless steel and glass aesthetic look
- Time-proven and highly reliable seals, lock, finish and top hinge systems
- Drop-down poster panel and diffuser for posting at ground level
- Electronic lighting ballasts
- Indoor use as standard, outdoor available by special order
- Marine grade 316 stainless steel
- Polyester power-coat paint finishing to the body profiles
- Full range of static and scrolling poster configurations
- Optional plinth designs
- Custom designs possible upon request
- Gas stay arms for safe door operation
| Outline Specification (Indoor unit) |
| |
|
|
| Poster Size |
: |
1800 X 1200 mm (other sizes available) |
| Safe Area |
: |
1760 x 1160 mm (other sizes available) |
| Glazing |
: |
8mm Toughened glass |
| Diffuser |
: |
Polypropylene |
| Posting |
: |
Dual poster clip poster retaining system,
Drop-down poster panel |
| Door Safety |
: |
Opened and held open using gas struts |
| Locking |
: |
Security key with dual latch closure system |
| Voltage |
: |
230 VAC, 50 Hz |
| Power |
: |
220W static and 265W scrolling (typical consumption) |
| SIGN TYPE |
DIMENSIONS [mm] |
MASS |
| |
|
|
| Wall mounted [static] |
2084 x 1484 x 143 |
130kg |
| Wall mounted [scrolling] |
2084 x 1484 x 143 |
135kg |
| Single-sided free standing [static] |
2484 x 1484 x 143 |
150kg |
| Single sided free standing [scrolling] |
2484 x 1484 x 143 |
155kg |
| Double sided free standing [static] |
2484 x 1484 x 286 |
180kg |
| Double sided free standing [scrolling] |
2484 x 1484 x 286 |
185kg |
| |
|
|
FSU plinth height 440mm as standard |
|
|
| (Note external units are available but have different dimensions.) |
|
|
