Debut


Highly flexible in size this illuminated and non-illuminated display-box is designed for indoor use and is available in wall or post mounted installation options. powdered-coated painted frame is available in a full range of colours.

Benefits

  • Budget illuminated or non-illuminated display panel
  • Available in multiple standard and custom sizes up to 1500 x 3000mm
  • Electronic lighting ballasts (illuminated unit only)
  • Glass or polycarbonate glazing—field replaceable
  • Aluminium construction with silver anodised or powder coated
  • paint finishing to customer colour specification
  • Optional mounting posts and frames available for free-standing applications
Outline Specification

Poster Size Available to accommodate any poster size
Overall Size : Width - Poster size +72mm
    Height - Poster size +72mm
    Frame Width 49mm
    Depth - 51mm (non-illuminated)
                132mm (single sided illuminated)
                168mm (double sided illuminated)
Glazing : 4mm Toughened glass or polycarbonate as specified
Diffuser Polypropylene or net
Posting Dual poster clip poster retaining system
Locking Concealed slide locks
Voltage 230 VAC, 50 Hz
Power 220W (1800 x 1200 mm unit typical consumption)



OVERALL SIZE DIMENSIONS

Width poster width + 72 mm
Height poster height + 72 mm
Frame Width 49 mm
Depth 51 mm [non-illuminated]
132 mm [single sided, illuminated]
168 mm [double sided, illuminated]
