Spotlight


This wall mounted display meets the latest health and safety requirements by offering bottom loading of the stretch PVC advertising media. The unit can be glazed in glass or polycarbonate for added protection of the media as well as being available without any glazing. Available in a number of sizes up to three metres wide.

Benefits

    • Bottom loaded vinyl meets new health and safety guidelines
    • Stretch vinyl advertising media with quick and simple keder tensioning system
    • Electronic lighting ballasts
    • Glass, polycarbonate or no glazing for physical protection in exposed sites
    • Indoor and outdoor use
    • Aluminium construction with power-coat paint finishing to customer colour specification
  • Wall mounted static configuration
  • Custom designs possible upon request
Outline Specification

Poster Size 2038 X 2038 mm 2338 x 2338 mm
Safe Area 1900 x 1900 mm 2200 x 2200 mm

Glazing unglazed, 10 mm toughened glass or 15mm polycarbonate as specified
Diffuser none
Posting Bottom loaded drop-down system with winch drive lift and tensioning system
Door Top hinged with gas strut stay arms
Locking Security key with dual latch closure system
Voltage 230 VAC, 50 Hz
Power 666W / 1017W (typical consumption)



SIGN TYPE DIMENSIONS [mm] MASS

Wall mounted [static] 2260 x 2260 x 240 350kg (10mm glass)
Wall mounted [static] 2560 x 2560 x 240 430kg (10mm glass)
