Universal Slim Contemporary


Edge-to-edge framed door style which is designed to enable easy field replacement of both glass and polycarbonate. New 'slim' profile. Tough powder-coat painted to a colour of your choice. Available as a static display configuration in both illuminated and non-illuminated versions.



Benefits

  • Contemporary fully glazed door but maintaining the ability to use polycarbonate sheet and the ability to replace in situ.
  • time-proven and highly reliable seals, lock, gas stay support and hinge systems.
  • Drop-down poster panel and diffuser for posting at the ground level - Non Illuminated Only
  • Full-fill lighting.
  • Electronic lighting ballasts
  • Glass or polycarbonate glazing—field replaceable
  • Indoor and outdoor use
  • Aluminium construction with powder-coat paint finishing to customer colour specification
  • Fire specification available for sub-surface applications.
  • Custom designs possible upon request



Outline Specification

Poster Sizes 6 Sheet - 1800 x 1200 mm
    4 Sheet - 1524 x 1016 mm
    (other sizes available)
Safe Area 6 Sheet - 1760 x 1160 mm
    4 Sheet - 1484 x 976 mm
    (other sizes available)
Glazing 6mm Toughened glass or polycarbonate as specified
Diffuser Corex Poster Panel or Net
Posting Dual poster clip poster retaining system,
Drop-down poster panel
Locking Security key with dual latch closure system
Voltage 230 VAC, 50 Hz
Power 6 Sheet, 186W, 4 Sheet 154W (typical consumption)



SIGN TYPE DIMENSIONS [mm] MASS

6 Sheet Wall Mounted [static] 1980 x 1380 x 74 89kg
4 Sheet Wall Mounted [static] 1704 x 1196 x 74 67kg
