Universal Designer


Edge-to-edge framed door style and veneered in a finish or material of your choice eg. stainless steel, wood effect laminate. This enables a very expensive looking product to be supplied at a cost effective price. The aesthetic flexibility extends to the plinth which is available in a multitude of designs and finishes. Available in all static and scrolling display configurations.

Benefits

  • Infill panels to cost effectively customise the design and quality of finish
  • Wide range of finishes, including anodising or powder coat edging with stainless steel or decorative laminate infils.
  • Contemporary fully glazed door
  • Glass or polycarbonate glazing—field replaceable
  • Time-proven and highly reliable seals, lock, finish and hinge systems
  • Drop-down poster panel and diffuser for posting at ground level
  • Standard or new long-life and Full-fill lighting options
  • Electronic lighting ballasts
  • Indoor and outdoor use
  • Aluminium construction
  • Full range of static and scrolling poster configurations
  • Optional standard plinth designs
  • Custom designs possible upon request
Outline Specification

Poster Size 1800 X 1200 mm (other sizes available)
Safe Area 1760 x 1160 mm (other sizes available)
Glazing 6mm Toughened glass or polycarbonate as specified
Diffuser Polypropylene or net
Posting Dual poster clip poster retaining system,
Drop-down poster panel
Locking Security key with dual latch closure system
Voltage 230 VAC, 50 Hz
Power 220W static and 265W scrolling (typical consumption)



SIGN TYPE DIMENSIONS [mm] MASS

Wall mounted [static] 1980 x 1380 x 148 98kg
Wall mounted [scrolling] 1980 x 1380 x 148 98kg
Single-sided free standing [static] 2627 x 1380 x 148 145kg
Single sided free standing [scrolling] 2627 x 1380 x 148 145kg
Double sided free standing [static] 2627 x 1380 x 180 182kg
Double sided free standing [scrolling] 2627 x 1380 x 180 182kg

FSU plinth height 600mm as standard
