Galleria
This curved and edge-lit unit is the ideal solution for pillar mounted applications. Different mounting pillars require different installation solutions so SMF also offers a bespoke design service to tailor the mounting and finishing of the unit.
Benefits
- Curved advertising lightbox ideal for mounting on columns
- Thin low profile design
- Glass or polycarbonate glazing—field replaceable
- Edge lighting using thin T5 lighting tubes
- Electronic lighting ballasts
- Indoor use only
- Aluminium construction with power-coat paint finishing to customer colour
specification
- Bespoke installation/cladding design service to suit specific locations
| Outline Specification |
| |
|
|
| Poster Size |
: |
1800 X 1200 mm |
| Safe Area |
: |
1760 x 1160 mm |
| Overall size |
: |
1956 x 1273 x 67 mm (Pillar mounted) |
| Glazing |
: |
6mm Toughened glass or polycarbonate as specified |
| Diffuser |
: |
Acrylic light distribution panel |
| Posting |
: |
Dual poster clip poster retaining system,
|
| Door |
: |
Side opening |
| Locking |
: |
Two concealed slide locks |
| Voltage |
: |
230 VAC, 50 Hz |
| Power |
: |
166 W (typical consumption) |
|
|
