Albion
The high aesthetic qualities of stainless steel and glass are used to create this handsome range of products. These are available in all free-standing and mounted configurations for static and scrolling poster displays.
Benefits
- Contemporary stainless steel aesthetic design
- Marine grade 316 stainless steel
- Indoor or outdoor use
- Time-proven and highly reliable seals, lock, finish and hinge systems
- Electronic lighting ballasts
- Glass or polycarbonate glazing—field replaceable
- Aluminium body with galvanised steel structure and stainless steel doors and plinth
- Full range of static and scrolling poster configurations
| Outline Specification |
| |
|
|
| Poster Size |
: |
1800 X 1200 mm (other sizes available) |
| Safe Area |
: |
1760 x 1160 mm (other sizes available) |
| Glazing |
: |
6mm Toughened glass or polycarbonate as specified |
| Diffuser |
: |
Polypropylene or net diffuser optionally available |
| Posting |
: |
Dual poster clip poster retaining system |
| Locking |
: |
Security key with dual latch closure system |
| Door |
: |
Top hinged door with gas stay arms |
| Voltage |
: |
230 VAC, 50 Hz |
| Power |
: |
220W static and 265W scrolling (typical consumption) |
| SIGN TYPE |
DIMENSIONS [mm] |
| |
|
| Wall mounted [static] |
2000 x 1453 x 169 |
| Wall mounted [scrolling] |
|
| Single-sided free standing [static] |
2600 x 1453 x 208 |
| Single sided free standing [scrolling] |
2600 x 1453 x 208 |
| Double sided free standing [static] |
2600 x 1453 x 208 |
| Double sided free standing [scrolling] |
2600 x 1453 x 208 |
| |
|
| FSU plinth height 600mm as standard |
|
|
|
