Ashlar Range


Stretch flex-face or rigid sheet advertising is accommodated in a front opening frame system. The frame can be made available in a variety of finishes as well as customised profile shapes. There is also a veneered design version that enables a very expensive looking product to be supplied at a cost effective price.

Benefits

  • Stretch PVC (Flex-face) or rigid advertising media
  • Simple posting technique
  • Slim profile
  • Long-life and “full-fill” lighting
  • Electronic lighting ballasts
  • Indoor and outdoor use
  • Aluminium construction with power-coat paint finishing to customer colour specification
  • Unique rigid back-panel/ reflector for mechanical integrity
  • Custom sizes, profiles and designs possible upon request
Outline Specification

Configuration Wall mounted
Visual sizes 1200 X 2400 mm
1500 x 3500 mm
3000 x 6000 mm
Overall sizes 1490 x 2690 mm
1790 x 3790 mm
3290 x 6290 mm
Glazing None
Diffuser None
Posting Stretch PVC printed sheet with 9mm Keder on four sides
Rigid printed polycarbonate or acrylic sheet
Locking Invisible latch system
Voltage 230 VAC, 50 Hz
Power 320 W
742 W
2,344 W
