Modillion Range
Available in all static and scrolling display configurations these glass or polycarbonate glazed medium format lightboxes are available in a range of designs
and of course sizes. The boxes can be wall mounted or placed on a monopole, again in a variety of styles, in either a central or offset configuration. The
scrolling products feature remote monitoring for the ultimate in audit, control and reliability.
Benefits
- High quality, highly reliable and well proven design
- Leading scroller technology with full remote control and diagnostics capability
- Standard and custom sizes up to 6m x 3m
- Time-proven and highly reliable seals, lock, finish and hinge systems
- Field replaceable glass door
- Electronic lighting ballasts
- Aluminium body with galvanised steel structure
- Polyester power-coat painted to customer specified colour
- Choice of four standard door profiles. Custom designs possible
- Choice of monopole designs and heights
- Full range of static and scrolling poster configurations
| Outline Specification |
| |
| Poster Size |
: |
10m2: 3700 x 2700mm
Other sizes available up to 6000 x 3000mm |
| Overall Size |
: |
4230mm x 3280mm |
| Monopole |
: |
Typically 2500mm to 3500mm.
Aluminium/glass clad galvanised steel |
| Glazing |
: |
Typically 14mm laminated glass |
| Poster Material |
: |
Paper 120—160g |
| Locking |
: |
Security key with dual latch closure system |
| Door Opening |
: |
Gas stay arms |
| Voltage: |
: |
230 VAC 50 Hz |
| Max Power |
: |
1200W scrolling |
| |
|
|
| Scroller |
|
|
| |
|
|
| Number of posters |
: |
5 to 7 depending on joining method |
| Modem |
: |
GSM |
| Remote control |
: |
Yes |
| Management reporting |
: |
Yes |
|
|
